Section I.4 Torsion of Thin - Wall Open Sections

The sections shown below are extruded sections

Example

• Example Problem 1 Maximum shear stress and angle of twist of a FORMED section
• Example Problem 2 Maximum shear stress and angle of twist of an EXTRUDED section
